GaN

Full Spectrum LED Products
Cover All Visible Light and Invisible Light

GaN

    Video Display

    General Lighting

    TV Backlight

    Mobile Phone Backlight

    Digital Signage

    Flip Chip

    Vertical

    Ultraviolet

    Mini

    Automotive

  • Indoor Display

  • Outdoor Display

    • Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    06A2121/1515/1212...P2-P40.5V/8, 10, 12nm binningHigh Brightness, Long Service Life
    08F1010/2121...P1.2-P40.3V/2nm binning
    08H1010/2121...P0.9-P40.3V/2nm binning
    Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    08DG1921/2525/2727…P4-P100.5V/10nm binningHigh Brightness, Long Service Life
    10A2727/2525/3535…P4-P10

    0.3V/2.5nm binning

    13C2727/3535P4-P16 0.3V/2.5nm binning
    14D2727/3535P4-P160.3V/2.5nm binning
    16A346/3535…P4-P160.3V/2.5nm binning

  • 0.2W

  • 0.5W

  • 1W

  • High Voltage

  • Filament

  • Horticulture Lighting

  • Full-color Lighting

  • Full Spectrum Lighting

    • Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    172835/3030…General Lighting22-24lm@60mA

    Test, High Brightness, Long Service Life

    182835/3030…General Lighting24-26lm@60mA
    272835/3030… General Lighting26-28lm@60mA
    30
    		2835/3030…General Lighting

    28-32lm@60mA

    Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    302835/3030…General Lighting60-65lm@150mA

    100% Test, High Brightness, Long Service Life

    322835/3030…General Lighting65-70lm@150mA
    342835/3030…General Lighting210lm/W@65mA-2D
    352835/3030…General Lighting220lm/W@65mA-2D
    402835/3030…General Lighting222lm/W@65mA-2D
    422835/3030…General Lighting223lm/W@65mA-2D
    452835/3030…General Lighting223lm/W@65mA-2D
    462835/3030…General Lighting225lm/W@65mA-2D
    Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    453535…General Lighting~170lm,350mA

    100% Test, Low Voltage, High Brightness, Long Service Life

    Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    18(9V)2835/3030…General Lighting~25lm@20mA

    100% Test, Low Voltage, High Brightness, Long Service Life

    26(9V)2835/3030…General Lighting~27lm@20mA
    34(9V)2835/3030…General Lighting~150lm@60mA 2D
    39(9V)2835/3030…General Lighting~153lm@60mA 2D
    43(9V)2835/3030…General Lighting~170lm/W@100mA 2D
    13(18V)2835/3030…General Lighting~22lm@ 10mA
    16(18V)2835/3030…General Lighting~60lm@ 30mA
    17(18V)2835/3030…General Lighting~63lm@ 30mA
    23(18V)2835/3030…General Lighting~67lm@ 30mA
    24(18V)2835/3030…General Lighting~72lm@ 30mA
    30(18V)2835/3030…General Lighting~75lm@ 30mA
    33(18V)2835/3030…General Lighting~77Im@ 30mA
    Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    103808/4015…Filament~130lm/W

    100% Test and Binning, Long Service Life, IP Protection

    143808/4015…Filament~150lm/W
    173808/4015…Filament~155lm/W
    183808/4015…Filament~160lm/W
    223808/4015…Filament~165lm/W
    283808/4015…Filament~183lm/W
    303808/4015…Filament~185lm/W
    15(6V)3808/4015…Filament~127lm/W
    41(6V)3808/4015…Filament~138lm/W
    16(FC)FPC BoardFlexible Filament~115lm/W
    20(FC)FPC BoardFlexible Filament~120lm/W
    22(FC)FPC BoardFlexible Filament~130lm/W
    23(FC)FPC BoardFlexible Filament~135lm/W
    Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    342835/3030…Horticulture Lighting

    PPE:2.9 umol/J -2D

    		100% Test, Low Voltage, High Brightness, Long Service Life
    352835/3030…Horticulture Lighting

    PPE:3.0 umol/J -2D

    422835/3030…Horticulture Lighting

    PPE:3.05-3.1 umol/J -2D

    40(FC)PCT3030…Horticulture Lighting

    PPE:3.15 umol/J

    55(VTF)3535…Horticulture Lighting

    PPE:2.5 umol/J

    Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    19B/G3030/5050…Landscape Lighting, Smart Home470/525nm100% Test, Low Voltage, High Brightness, Long Service Life
    20B/G3030/5050…Landscape Lighting, Smart Home470/525nm
    30B/G3030/5050…Landscape Lighting, Smart Home455/525nm
    35B/G3030/5050…Landscape Lighting, Smart Home475/525nm
    Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    303030/2835...Circadian Lighting…380-420nm100% Test, Low Voltage, High Brightness, Long Service Life
    313030/2835…Circadian Lighting…400-420nm
    323030/2835…Circadian Lighting…425-440nm, 455-475nm
    353030/2835…Circadian Lighting…400-420nm, 425-440nm, 460-480nm

  • TV Backlight

    • Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    30(Wide Angle)2835/4014/2016Backlight~88mW@60mA100% Test, Low Voltage, High Brightness, Long Service Life
    353030...Backlight~160lm@400mA 2D
    363030…Backlight~200lm@600mA 2D
    39(FC)3030/CSP...Backlight~1300mW@700mA
    40(12V)3030…Backlight~175lm@100mA 2D


  • 020

    • Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    420.4T/0.6T…Mobile Phone/Tablet43-48mW

    Binning, Long Service Life, 100% ESD Test

    360.4T/0.6T…Mobile Phone/Tablet42-45mW
    260.4T/0.6T…Mobile Phone/Tablet40-43mW
    200.4T/0.6T…Mobile Phone/Tablet39-42mW
    Low VF0.4T/0.6T…Mobile Phone/Tablet42-48mW
    High Voltage0.4T/0.6T…Mobile Phone/Tablet65-75mW
    Low Blue Light0.4T/0.6T…Mobile Phone/Tablet39-45mW

  • 0.06W

    • Product Series and Product Types Applicable Package Application Specification Advantages
    8 0603/7-Segment Display Through-hole LED lamp 7.5-8.5mW@5mA 100% Test, High Brightness, Long Service Life
    10 0603/7-Segment Display Through-hole LED lamp 13-16mW@10mA
    12 0603/7-Segment Display Home Appliances/Keyboard Light… 24-28mW@20mA Binning, Long Service Life, 100% ESD Test
    15 0603/7-Segment Display Home Appliances/Keyboard Light… 30-36mW@20mA
    31
    		 0603/7-Segment Display Keyboard Light… 39-45mW@20mA 100% Test, High Brightness, Long Service Life

  • FC

    • Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    20COB…General Lighting~78lm/W@150mA100% Test,High Brightness, Long Service Life
    22COB…General Lighting~110lm/W@150mA
    31COB…General Lighting~140lm/W@150mA
    32COB/Ceramic…General Lighting~175lm@0.5A
    35COB/Ceramic…General Lighting~180lm@0.5A
    40COB/Ceramic…General Lighting~360lm@1A
    45Ceramic…General Lighting~390lm@1A
    55Ceramic…General Lighting~420lm@1A
    60Ceramic…General Lighting~440lm@1A
    75Ceramic…General Lighting~460lm@1A

  • VTF

    • Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    15G7016Smart Wearable>17.5mW@20mAHigh Brightness, Low VF, Flexible, Customized
    18BCOB,3535…Mobile Lighting>420mW@350mA
    24BCOB,3535…Mobile Lighting>500mW@350mA
    26B/GCOB,3535…Stage Light, Mobile Lighting>550mW@350mA,>200mW@350mA
    32BCOB,3535…Stage Light, Mobile Lighting>600mW@350mA
    38B/G5050,3535…Stage Light, Spotlight>600mW@350mA,>240mW@350mA
    47B/G5050,3535…Stage Light, Spotlight>1500mW@1000mA,>550mW@1000mA
    55B5050,3535…Stage Light,Landscape Lighting>660mW@350mA
    63B/G5050…Stage Light,Spotlight>1650mW@1000mA,>720mW@1000mA
    72B5050…Stage Light,Landscape Lighting>1700mW@1000mA
    40WCOB,3535…Stage Light,Spotlight>100lm@350mA
    80WCOB,3535...General Lighting>160lm@350mA

  • UV

    • Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    203535Sterilization and Disinfection270~280nmEnergy is Concentrated; Sterilization Efficiency is High
    213535Sterilization and Disinfection270~280nm
    303535Sterilization and Disinfection270~280nm
    426868Sterilization and Disinfection270~280nm
    115050/2835Manicure/Mosquito Trapping360~370nmHigh Brightness, Low VF, Flexible, Customized
    135050/2835Manicure/Mosquito Trapping360~370nm
    456868Curing365/385/395/405nm
    556868Curing365/385/395/405nm

  • Mini Display

  • Mini Backlight

    • Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    05LCOB/1010/All-in-one…P0.6-P1.20.3V/2.5nm binning100% Test, High Brightness, Long Service Life
    06LCOB/1010/All-in-one…P0.6-P1.20.3V/2.5nm binning
    08LCOB/1010/All-in-one…P0.6-P1.20.3V/2.5nm binning
    Product Series and Product Types Applicable Package Application Specification Advantages
    12 Laptop... General Binning: 1.5nm/0.05V/3% 100% Test, High Precision, High Contrast Ratio, Long Service Life
    15 TV... Wide Angle Binning: 1.5nm/0.05V/3%
    25 TV... Wide Angle Binning: 1.5nm/0.05V/3%

  • Automotive

    • Product Series and Product TypesApplicable PackageApplicationSpecificationAdvantages
    14Decorative Light…30mA30-36mW@20mA100% Test, Stable Performance, AEC-Q102 Certification, and Service Life is Long
    18Reading Light…90mA70-85mW@60mA
    24Decorative Light…250mA197-230mW@120mA
    34Daytime Running Light…240mA190-210mW@120mA
    43Daytime Running Light…500mA530-620mW@350mA
    24(FC)Daytime Running Light…500mA230-260mW@150mA
    47(VTF)Automotive Headlight...3.2A1500-1800mW@1A
